Verti-Drain® 2216


Verti-Drain® 2216

The Verti-Drain 2216 is able to work at a high speed in hard soils and can take solid tines with a diameter up to 24mm (1″).


Working width m:1.6 m
Working width inch:63 inch
Max working depth mm:225 mm
Max working depth inch:9 inch
Working speed at hole spacing 65 mm kmh:1.79 km/h
Working speed at hole spacing 2-12 mph:1.1 mph
Weight kg:840 kg
Weight lbs:1851 lbs
Hole distance with 12 mm tines mm:65 mm
Hole distance with 12 x 6 tines inches:2.5 inch
Hole distance with 18 mm tines mm:130 mm
Hole distance with 34 x 9 tines inches:4 inch
Hole spacing driving distance direction mm:25 - 195 mm
Hole spacing distance driving direction inches:1 - 7.5 inch
Max diameter-solid tine mm:24 x 225 mm
Max diameter-solid tine inches:1 x 9 inch
Max diameter hollow tine mm:25 x 225 mm
Max diameter hollow tine inches:1 x 9 inch
Min tractor hp required:45 HP
Min lifting capacity kg:1050 kg
Min lifting capacity lbs:2314 LBS
Max capacity with spacing 65 mm m2hr:2796 m²/hr
Max capacity with spacing 2-12 ft2hr:30096 ft²/hr
Three-pointhitch:3-Point CAT 1/2
Rpm max:540 rpm
Gear case oil:80W90
Lubricant:EP 2
Dimensions mm:1210 x 1700 x 900 mm
Dimensions inch:47.6 x 66.9 x 35.4 inch
